BT40- C32-105 powerful milling chuck arbor for straight type BT40 C32 Collet Chuck for CNC working
We are Pingyuan Best Machine Tools., Co., Ltd., the high-end cnc machine tools manufacturer and supplier from China. Our products line is over 100 models, mainly include: Collet Chuck , Tool Holder Device , Collet , Spanner , Pull Stud and Nuts , Etc. Collet chuck also include many standards and models like: ISO series, BT30 series, BT40 series, HSK series, NBT series and CAT series, etc.
|
Brand Name |
BESTMYT |
|
Model Number |
BT40-C32-105 Power Type tool holder for stone |
|
Color |
bright white with black |
|
Materials |
40CrMnTi Alloyed case hardened steel,black-finished and precisely grind. |
|
Taper tolerance |
<AT3 |
|
Precision |
≤0.001 mm |
|
Surface Roughness |
>0.8mm |
|
Roundness |
<0.8μm |
|
Carbonizing depth |
08mm±0.2mm |
|
Hardness |
HRC58-62 |
|
Balance |
G2.5 / 4000-6000RPM |
|
Suitable collet type |
straight type collet C16/20/25/32/42 |
|
Suitable tool accessory |
BT pull stud, hook spanner |
|
Service |
Customized OEM/ODM |
|
Function |
Suitable for drill iron bed, grinder, lathe,process,carving Machine, Engraving and Milling machine etc various stone maching centers and precion lathes. |
|
Applicable cutters |
vertical disc cutter, sets of type of milling cutter, face milling cutter, milling cutter, three face milling cutter .Mechanical spindle and cutting tools and other accessories. |
1. Raw materials: Carbonized steel high harden ability, especially high temperature impact toughness under guaranteed harden ability.
2. Production capacity: Optimizing the industrial structure makes our production efficient, cost-effective and very good quality.
3. Application: Vertical/horizontal/gantry cnc machining.
