Borehole Submersible Water Pump For Deep Well

Borehole deep well submersible water pump-25

The Borehole Submersible Water Pump For Deep Well is designed specifically for water extraction from deep well, integrating an efficient energy-saving motor and precision sealing system to ensure stable operation even in harsh well conditions. Based on fluid dynamics principles, it generates strong suction and thrust through the rotation of the impeller inside the pump, drawing water from the bottom of the well and delivering it to the surface. Suitable for agricultural irrigation, industrial cooling, and urban water supply among other fields. We offer customization services to meet your different application needs.

Each Submersible pump undergo rigorous testing before leaving the factory to ensure outstanding quality and stable performance.

The Deep Well Submersible Pump is available in Cast iron, SS 304, SS 316, SS 316 L, Duplex SS, SS 904 L.

Borehole Submersible Water Pump For Deep Well Technical Parameters Part of parameters, for reference only.

Diameter Inch (")	Model	Power (hp)	Rated Flow (m3/h)	Rated Head (m)
7"	175QJ20-143/11	20	20	143
7"	175QJ32-96/8	20	32	96
7"	175QJ50-36/3	10	50	3.6
8"	200QJ20-256/19	40	20	256
8"	200QJ25-70/5	12	25	70
8"	200QJ32-130/10	30	32	130
10"	250QJ40-104/8	25	40	104
10"	250QJ50-150/10	50	50	150
10"	250QJ63-100/5	40	63	100
10"	250QJ100-216/12	135	100	216
10"	250QJ160-45/3	40	160	45
12"	300QJ200-100/5	120	200	100
12"	300QJ240-66/3	100	240	66
12"	300QJ300-80/4	150	300	80

Submersible Borehole Pumps Features

1. Motor and pump are integrated, simple structure;

2. Easy to install, use, disassemble and maintain;

3. Taking little floor space;

4. No pollution to water source.
