Thread rolling machine
This model is widely praised for its rational price, easy maintenance and high quality. besides axial and radial process, it is used to process regular and irregular bolt, through screw etc. with optional embossing roller embossing roller. the through screw made with this machine in hebei standard parts base has been exported to US Canada and Europe.
Specification:
| Pressure of roller max: | 150KN | Rotary speed of main shaft: | 36,47,60,78(r/min) |
| Working dia: | 4-48mm | Feed speed of movable shaft: | 5mm/s |
| OD of roller: | 120-170mm | Thread length: | no limits |
| BD of roller: | 54mm | Main power: | 4kw |
| Roller width max: | 100mm | Hydraulic power: | 2.2kw |
| Dip angle of main shaft: | +-5degree | Weight: | 1700kg |
| Center distance of main shaft( stroke): | 120-240mm | Size: | 1500*1380*1140mm |
If you are interested in the product, contact 2bvideo.com for more information for more information
