Automatic pallet wrapping system with rotating turntable and pallet conveyors
Basic requirement:
Pallet dimension: L1200mm * W1200mm * H2000mm
Weight: max.1000kgs
Volt: 380volt, 50Hz & 3 phase
Supply scope:
1. Mast 1set
Height: to be designed according to the packing height 2,000mm and the turntable height 550mm.
Carriage lift motor: SEW brand.
2. Film carriage 1set
Film carriage on the front of the tower
Stretch film: Film thickness: 25μm; Film width: 500mm; Inner diameter: 76mm; Outer diameter: 240mm;
Max. Weight: 13.8kgs;
Open-door pre-stretch standard film carriage. Powered pre-stretch film carriage 250% (1:3.5);
Motor: SEW brand; Motor power: 0.37kw
Film carriage lifting driving: chain driving, good stability and high reliability
3. Turntable 1set
Diameter: 1800mm; turntable height: 550mm.
3 strand chain conveyor, with powder coated steel to cover between chains;
Turntable speed max. 15rpm;
Slew bearing driven;
Motors: SEW brand, turntable motor should be covered with steel board.
4. Film delivery device 1set
After finishing stretch wrapping, the film will be cut and clamped automatically.
Air blowing to wrap film head into pallet.
Hot melt cutting wire to cut the film, and then wipe the film tail.
Pneumatic component: FESTO brand
5 Control system 1set
Table type control cabinet
4-8 program can be set separatedly for different product
Proximity switch on the film carriage should be mounted with M12 thread.
Electrical brands:
|
No. |
Item |
Brand |
Origin |
|
1 |
PLC |
Siemens |
Germany |
|
2 |
Touch screen |
Siemens |
Germany |
|
3 |
Inverter |
Siemens |
Germany |
|
4 |
Proximity switch |
Omron |
Japan |
|
5 |
Limit switch |
Omron |
Japan |
|
6 |
Power switch |
Schneider |
France |
|
7 |
Relay |
Omron |
Japan |
|
8 |
Photoeye |
SICK, plug -in |
Germany |
|
9 |
Pneumatic parts |
Festo |
Germany |
|
10 |
Motor |
SEW |
Germany |
If you are interested in the product, contact 2bvideo.com for more information for more information
