Product details
Ductile cast iron pipe for compressive-sewage
Ductile cast iron pipe for compressive-sewage, we can also call sewage cast iron pipe is one kind of cast iron sewage pipe for sewage. Ductile iron pipes are available in a range of diameters from 80mm to 1600mm and are suitable for both potable water transmission and distribution (in accordance with BS EN 545) and sewerage (in accordance with BS EN 598). Ductile iron pipes are simple to joint, can be laid in all weather conditions and often without the need for selected backfill. Its high safety factor and ability to accommodate ground movement make it the ideal pipeline material for a wide range of applications

Our compressive-sewage pipe was awarded EN598 as well as ISO7186 certificate, the size can inculde DN80-1200mm.

Internal coating:
  • Portland cement mortar lining
  • Sulphate Resistant cement mortar lining
  • High-Aluminum cement mortar lining
  • Fusion bonded epoxy coating
  • Liquid epoxy painting
  • Black bitumen painting
External Coating:
  • Zinc+bitumen(70microns) painting
  • Fusion bonded epoxy coating
  • Zinc-aluminum alloy+liquid epoxy painting
Product details:

DN(mm) DE(mm) Thichness(mm)
80 98 4.4
100 118 4.4
125 144 4.5
150 170 4.5
200 222 4.7
250 274 5.5
300 326 6.2
350 378 6.3
400 429 6.5
450 480 6.9
500 532 7.5
600 635 8.7
700 738 8.8
800 842 9.6
900 945 10.6
1000 1048 11.6
1100 1152 12.6
1200 1255 13.6

Cooperative partner:

cooperative


Except ductile cast iron pipe, Houming also provide seamless steel pipe, welded steel pipe, stainless steel pipe for your choosing.
