Application field of HOME FREEZE DRYER :
Vegetables, aquatic products and meat, seasonings, instant beverages, convenience foods, traditional Chinese medicine, materials, biology, and more
Characteristics of HOME FREEZE DRYER:
1. Humanized design of the entire machine, plug and play, beautiful appearance, compact structure, and high cost-effectiveness.
2. The integrated design of the box and trap makes the sublimation channel shorter, which is conducive to the rapid sublimation of a large amount of water vapor.
3. The original imported refrigeration compressor has a large refrigeration capacity, high efficiency and energy conservation, long service life, and low noise.
4. The use of aerospace grade high transparency organic glass doors allows for real-time observation of the entire process of sample freeze-drying changes.
5. Easy to operate and highly automated, the entire freeze-drying process can be completed with just one button.
6. Pre set standard freeze-drying process, without the need for in-depth understanding of cumbersome freeze-drying principles and processes, one click process import.
7. Intelligent fault diagnosis technology, displaying fault information in text form, greatly facilitates equipment maintenance and fault repair.
8. Safety locking function. Prevent incorrect operation to modify system status and process parameters, resulting in freeze-drying failure or instrument damage.
9. The intelligent energy-saving and temperature control technology of the partition has high temperature control accuracy, significant energy-saving effect, and stable and reliable system.
10. One click quick defrosting technology, safe and efficient.
11. Adopting PLC control system, one click start, easy to operate;
12. The temperature and vacuum protection during the freeze-drying process ensure the normal operation of the equipment and ensure the drying effect;
Optional: Oil free vacuum pump to solve problems such as oil change, oil mist, and corrosion prevention;
Technical Data OF 4S home freeze dryer:
|
型号model |
HT-4S |
|
隔板面积 Partition area |
0.36㎡ |
|
冷阱温度 Cold trap temperature |
≤-50℃ |
|
隔板层数 Number of clapboard layers |
4+1 |
|
极限真空度（空载） Ultimate vacuum（Empty） |
≤10pa |
|
处理量（KG/批） Processing capacity (KG/batch) |
4-6 |
|
板层间隔（mm) Layer spacing |
45 |
|
加热方式 Heating method |
electrical heating |
|
电源 Power supply |
220V/50HZ |
|
整机功率（含泵） Overall power |
1550w |
|
物料盘尺寸（W*L） Material tray size |
197*455mm |
|
|
4 layer |
|
外形尺寸（W*D*H） Overall dimensions |
750*560*870mm |
