LED UV is a low-temperature light source with low heat radiation. It can replace the traditional mercury UV lamp, which can reduce the defects of high temperature on the surface of the illuminated object and cause product deformation. The LED-UV light source emits high-purity single-band ultraviolet light, which has less damage to the skin and eyes. In addition, the LED UV light source can emit light without the excitation of instantaneous high voltage, and the safety is greatly enhanced.

The LED UV light source is installed on the flat UV curing machine and the curved UV curing machine to become a special LED UV curing machine. It has a good application in the cosmetics industry with the screen printing machine, and the application in the automatic screen printing machine is also gradually popular.

M-3000LEDUVS Cylinder UV Drying Machine//Usage and characters
Guide	It is mainly used for drying the ink layer after printing UV ink on hollow bottle products made of various plastics, metals and glass; Compact structure, high curing efficiency, widely used in cosmetics, plastic packaging and other industries; The bottle can be automatically rotated after entering the curing unit, so that the UV light can completely irradiate the surface of the bottle and improve the curing efficiency; Stainless steel sheet conveyor belt, better temperature resistance; At present, the more environmentally friendly ink drying method; A light-emitting diode is used to light up and emit ultraviolet light with a main peak of about 400 nm, and the acrylic resin of the ink is irradiated on the ink layer to cause cross-linking and curing of the ink. Water cooling system is adopted to improve the service life of LED UV light source.
Application fields	Electron, Hardware, Auto, Toys, Gifts, Plastics parts， Plastics products, House appliances, work of art, Stationery, Ornament, cosmetic, sports apparatus .UV drying for UV ink .
M-3000LEDUVS Cylinder UV Drying Machine//Parameter
Technical parameters	Max. curing size of workpiece: Cylinder:300X200mm Conveyor speed:0~10m/min ; Total power:3.5KW; Outline dimension:2100X600X1700mm ; Conveyer width: 400mm; LED Lamp Wattage: 2*1500W; Power supply: 1 Phase 220V.
Works supply	Power： 1 phase 220V.
Package list	Package dimension:2.250×0.870×1.900m; Gross weight:330KG; CBM: 3.7193
H.S.Code	8443198000
Certificate	CE
M-3000LEDUVS Cylinder bottle UV Curing Machine//Advantage
Function	Stainless steel conveyor belt, high temperature resistance; Driven by a famous brand motor, the speed can be adjusted steplessly, which is convenient to adjust the conveying speed according to the product characteristics; LED UV light source, the surface temperature of the product is low, and the product is not easily deformed during the curing process; No need for high pressure excitation, high safety performance, saving tender tubes With a water cooling system, it can effectively reduce the temperature of the LED tube and improve the service life; UV ink light curing for the surface of round objects improves the light curing effect of round objects.
Main configuration	Operation panel LED UV system Water cooling system Conveyor and rotating device
Accessories included	Operation instruction in English；

Details

LED bottle UV curing machine is a device that uses LED light source to emit ultraviolet light of a specific wavelength to cure UV ink or coating on the surface of the bottle.

Working principle:

LED light source is used as the luminous body, and ultraviolet light is emitted to stimulate the photoinitiator in the photosensitive material to produce a chemical reaction, so that UV materials such as coatings, inks, glues, etc. are quickly cured in a short time. Compared with traditional mercury lamp curing machines, LED light sources have higher energy conversion efficiency and longer service life.

Structural composition:

LED light source system: This is the core component of the curing machine, which is composed of multiple LED lamp beads and can emit high-intensity ultraviolet light. LED lamp beads have the advantages of high luminous efficiency, long life, and low energy consumption.
Heat dissipation system: Since LED light sources generate heat when working, the heat dissipation system is required to dissipate the heat in time to ensure the stability and service life of the light source. There are two main heat dissipation methods: air cooling and water cooling.
Conveying system: It is used to transport bottles through the UV curing area to ensure that the bottles can be evenly exposed to ultraviolet light. The speed of the conveying system is usually adjustable to meet different production needs.
Control system: The power, irradiation time, conveying speed and other parameters of the LED light source can be precisely controlled to ensure the stability and consistency of the curing effect.

Advantages:

Fast curing speed: The ultraviolet energy emitted by the LED light source is high, which can quickly cure the UV material in a short time, greatly improving production efficiency.
Energy saving and environmental protection: The energy consumption of the LED light source is low, which can save a lot of energy compared with the traditional mercury lamp curing machine. At the same time, the LED light source does not contain harmful substances such as mercury, which is more environmentally friendly.
Long service life: The service life of LED lamp beads is usually more than tens of thousands of hours, which reduces the maintenance and replacement frequency of equipment and reduces production costs.
Wide range of applications: It can be applied to bottles of various shapes and materials, such as glass bottles, plastic bottles, etc., and has good curing effects for different types of UV materials.
