Model |
|
BDD15 |
|
Working mode |
|
Electric |
|
Driving mode |
|
Walkie |
|
Rated load |
Q (kg) |
1500 |
|
Load centre distance |
c (mm) |
500 |
|
Front suspension |
x (mm) |
745 |
|
Wheel spacing |
Y (mm) |
1200 |
|
Weight (with battery) |
kg |
380 |
|
Wheels |
|
nylon |
|
Wheel size, front wheel |
|
Φ180*50 |
|
Wheel size, rear wheel |
|
Φ80×70 |
|
Wheel, front and rear number (x = drive wheel) |
|
2/2 |
|
Front wheel |
b10(mm) |
690 |
|
Rear wheel |
b11(mm) |
410/525 |
|
Lift height |
h1(mm) |
1600 |
|
Height of door frame retracted |
h3(mm) |
2090 |
|
Maximum height of gantry during operation |
h4(mm) |
2100 |
|
Lower height |
h13(mm) |
90 |
|
Overall length |
l1(mm) |
1860 |
|
Length of fork |
l2(mm) |
1100 |
|
Overall width |
b1(mm) |
800 |
|
Fork size |
S/e/l (mm) |
50×160×1100 |
|
Fork width |
b5(mm) |
320-1030 |
|
Distance center off clearance |
m2(mm) |
40 |
|
Channel width, tray 1000 x1200(1200 cross fork placement) |
Ast(mm) |
2305 |
|
Channel width, pallet 800 x1200(1200 placed along fork) |
Ast(mm) |
2258 |
|
Turning radius |
Wa(mm) |
1425 |
|
Speed up, full load/ no load |
m/s |
0.08/0.1 |
|
Drop speed, full load/ no load |
m/s |
0.15/0.12 |
|
Driving brake |
|
Mechanical braking |
|
Lift motor power |
kW |
2.2 |
|
Battery voltage/ rated capacity |
V/Ah |
12/120 |
|
Battery weight |
Kg |
43 |
|
Driver's Ear Noise Level DIN12053 |
dB (A) |
≤70 |
Jiangsu Lundi Forklif Co.Ltd.is a logistics equipment R&D and production supplier.The company has high-tech
Q1:Are you a factory?
A1:Of course.Jiangsu Lundi Forklift Co.Ltd.was founded in 2016but has experienced research and development teamto meetyourneeds
Q2. How lona does it take to execute myorder?
A2.Please tell us the quantity and model number of the products you are about to order. so that wewigiveyouadetaiedschedule
Q3.Do you offer custom design?
A3.Custom desiqn is surely available.We have very rich experience in customizing Forklifts.
Q4: How about the sample policy?
A4 We can accept sample order for testing quality.But sample and express charge should be on customer's account
Q5: How about the deliverytime?
A5:Usually Lundi producing time is 15-20 working days after we receive the advanced payment
For some standard productswe have most in stock and could delivervimmediately
Q6:What is your payment term?
A6:T/T or L/C,if you want any other way,please contact us.
Q7:MayIvisit your company?
A7.We are always happy to serve you Our factory is located in TaizhouJiangsu province.There are international flights nearby and the traffic is well developed.f you would like to order our prod ucts and visit our company please contact us for an appointment
