Technical Parameters of Mud Pump
Model
F-500
F-800
F-1000
F-1300
Max,Liner Size x stroke
170x191(6-3/4x7.5)
170x229(6-3/4x9)
170x254(6-3/4x10)
180x305(7x12)
Strokes Rating,r/min
165
150
140
120
Power Rating,KW(HP)
373(500)
597(800)
746(1000)
969(1300)
Gear Type
4.286:1
4.185:1
4.207:1
4.206:1
Suction Inlet Flange,in
8
10
12
12
Discharge Outlet Flange,in
4
5
5
5
Pinion Shaft Dia.,mm(in)
139.7(5-1/2)
177.8(7)
196.9(7-3/4)
215.9(8-1/2)
Key,mm(in)
31.75x31.75(1-1/4x1-1/4)
44.45x44.45(1-3/4x1-3/4)
50.8x50.8(2x2)
50.8x50.8(2x2)
Valve Pots
Valve-Over-Valve,API #5
Valve-Over-Valve,API #6
Valve-Over-Valve,API #6
Valve-Over-Valve,API #7
Approx.Weight,kg(lb)
9770(21540)
14500(31970)
18790(41420)
26700(54170)
Model
F-1600/1600L
F-1600HL
F-2200
F-2200HL
Type
Triplex single acting piston
Triplex single acting plunger piston
Triplex single acting piston
Triplex single acting plunger piston
Max,Liner Size x stroke
180x305(7x12)
190x305(7-1/2x12)
230x356(9x14)
230x356(9x14)
Strokes Rating,r/min
120
120
105
105
Power Rating,KW(HP)
1193（1600）
1193（1600）
1640（2200）
1640（2200）
Gear Type
4.206:1
4.206:1
3.512:1
3.512:1
Discharge Outlet Flange
5"Flange,5000psi
5"Flange,10000psi(110mm)
5"Flange,5000psi(130mm)
5"Flange,10000psi(130mm)
Pinion Shaft Dia.,mm(in)
215.9(8-1/2)
215.9(8-1/2)
254(10)
254(10)
Key,mm(in)
50.8x50.8(2x2)
50.8x50.8(2x2)
63.5x44.45(2-1/2x1-3/4)
63.5x44.45(2-1/2x1-3/4)
Valve Pots
Valve-Over-Valve,API #7 L type,API #7
L Type,API #7
Valve-Over-Valve,API #8
L type,API #8
Approx.Weight,kg(lb)
24791(54660)/27020kg(57100lb)
29400(64820)
38460(84790)
44000(94980)
Technical parameters:
Rated Power : 960 KWWeight (approx): 24.7 Tons
J. Power end lubrication system adopts splash and forced lubrication
K. Central lubrication manifold with steel tubing for feeding all main, eccentric and pinion bearings, pressurized lubrication for lower crosshead slide and longer cross head life
Companies adhere to the purpose of "quality first,scientific management,customer first,integrity-based",which are in accordance with the "integrity,pragmatic,pioneering,innovative" spirit of enterprise,so as to meet the needs of users with first-class service.
Warmly welcome friends from all walks of life to review,cooperate and create brilliance together!
The Company`s Main Products:
190 series gas engine parts,diesel engine parts,oil mud pump,turbocharger.
190 series diesel/gas engine and generator,marine diesel engine,coal gas generator.
190 series engine overhaul and maintenance.
OEM gas engine and oil engine.
The operation and maintenance of power station.
Quality Concept:
Quality is the starting point for value,brand and dignity.Quality must meet standards,meet demand,and satisfy customers."Quality first,reputation first."is the company`s unremitting pursuit!
Overhaul Cases:
After nearly ten years of exploration and accumulation, the company has formed a system of after-sales service system and complete technical support. At present, the company's maintenance service business has been extended to home and abroad.
