steel wire 8mm 9mm 10mm used for post-tensioning technology in various shapes prestressed concrete structures, and widely used for electric concrete poles, civil engineering constructions railway sleeper,etc
Standard:GB/T5223 BS 5896 ASTM A421
Wire surface: Spiral ribbed ,Plain smooth ,Indented.
PRAMETER OF PRESTRESSED CONCRETE WIRE:
| Nominal Diatmeter(mm) | tolerance(mm) |
Cross sectional area (Sn/mm^2) |
Weight per meter(cg/m) |
| 4.00 | ±0.04 | 12.57 | 98.6 |
| 4.80 | ±0.04 | 18.10 | 142 |
| 5.00 | ±0.05 | 19.63 | 154 |
| 6.00 | ±0.05 | 28.27 | 222 |
| 6.25 | ±0.05 | 30.68 | 241 |
| 7.00 | ±0.05 | 38.28 | 302 |
| 7.50 | ±0.05 | 44.18 | 347 |
| 8.00 | ±0.06 | 50.26 | 394 |
| 9.00 | ±0.06 | 63.62 | 499 |
| 9.50 | ±0.06 | 70.88 | 556 |
| 10.00 | ±0.06 | 78.54 | 616 |
| 11.00 | ±0.06 | 95.03 | 746 |
| 12.00 | ±0.06 | 113.1 | 888 |
My name is Pillar Wang from Shandong Xindadi Holding Group Co.,Ltd.
Our company are professional in PC wire and cold drawn manufacturering,
Material: SWRH82B/77B
Gauge size(mm): 4.8mm 5.0mm 6.0mm 6.25mm 7mm 8mm 9mm 10mm 11mm
If you have this kind of requirement,we would like to supply good quality and service.
Welcome to inquiry
If you are interested in the product, contact 2bvideo.com for more information for more information
The information of 2bvideo.com limited shown above is provided by the user or collected on the network. Video 2B does not guarantee the authenticity,accuracy and legitimacy of 2bvideo.com limited information. Video 2B does not involve legal relationships and disputes between users arising from transactions other than secured transactions on this website. Disputes shall be settled by you through negotiation. If you are the person in charge or relevant employee of this enterprise, if you find that the enterprise information is incorrect or want to manage thiscompany, please contact us jacklee1558@gmail.com, after you claim the enterprise, you can obtain management permission, publish supplyand demand information, bring consulting orders, and remove page advertisements.
Main Product:
Prestressed Concrete Wire,
PC Strand,
PC Steel Wire,
High Tensile Steel Wire ,
HTS Wire,
Tendon Wire
