All Servo Continuous Motion Side Sealer

3 year ago
79 0
Product details

All Servo Continuous Motion Side Sealer With Outfeed


Shrink Tunnel Technical Features

Blowing system installed below  with the whole shrinking process visible through the heat-resistant window.

Conveyor speed and air volume controlled by inverters, wind hole openess and blowing direction adjustable.

Chamber  can be opened ,easy for cleaing and maintenance.


Automatic Sealing And Shrinking Series Scope of Application

Suitable for the packing demands of the mass production in industries suck like electronics ,hardware,platic, software,food,printing, pharmaceutical,floors and ceramics.

Applicable films: POF



All Servo Continuous Motion Side Sealer Technical Features

Continuous-motion design,non-stop product feeding, cross sealing chasing in cycle,perfect packing effect in super hi-speed.

All-servo operation system, parameters computerized just by inputting product dimensions,simple and user-friendly.

Feeding system can spontaneouly sychronize the speed according to the packing speed of the host machine.


All Servo Continuous Motion Side Sealer

Model
FL-5545TBJ
SM-5030LX 2M Finger Push Conveyor
Machine Dimensions (mm)
2854 X 1564 X 1348 1872 X 1035 X 1305 2000 X 550 X 1000
Tunnel Chamber Size (mm) / 1500 X 500 X 300 /
Max Packing Size (mm) L
Length Unlimited
1300 X 400 X 250 500 X 380 X 130
Max Packing Size (mm) W+H(mm)
≤400
/ /
Cross Sealing Size L/H (mm)
520/150 / /
Capacity (pcs/m) 80~120
0-20 m/min /
N.W. (kg)
1100 650 220
Power (kw)
4 16 0.4

Power supply

1PH 220V 50/60Hz
3PH 220V/380V 50/60Hz
1PH 220V 50/60Hz

Air pressure kg/cm2)

6~8
/ /
Applicable Film
POF
POF/PE
/
