Pressure range |
|
||
|
Pressure range |
-100kPa, 10kPa, 35kPa, 70kPa, 100kPa, 250kPa, 400kPa, 600kPa, 1MPa, 1.6MPa, 2.5MPa, 4MPa, 6MPa, 10MPa, 16MPa, 25MPa, 40MPa, 60MPa, 100MPa(bar and psi unit available) |
||
|
|
Pressure reference |
Gauge pressure | Absolute pressure | Sealed gauge pressure |
|
|
Overpressure |
200%F.S.(<25Mpa) | 150%F.S(≥25Mpa) |
||
|
|
Output signal |
|
|
|
Output |
4 to 20mA |
||
|
|
Specification |
|
|
|
Accuracy (linearity, repeatability and hysteresis) |
±0.5%F.S. (Typical) |
||
|
|
Excitation |
24VDC |
|
|
Compensated temp. |
-10-70ºC(typical) | -20-85ºC(available) |
||
|
|
Operating temp. |
-20-125ºC |
|
|
Storage temp. |
-40-125ºC |
||
|
|
Zero temp. coefficient |
±1.5%F.S.max.( -10-70ºC) |
|
|
Span temp. coefficient |
±1.5%F.S.max.( -10-70ºC) |
||
|
|
Pressure connection |
see last page ”how to order” |
|
|
Protection |
IP65 |
||
|
|
Housing material |
Stainless steel 304 (SS316 for sensor inside) |
|
|
O-ring |
NBR, Viton |
||
|
|
Housing and diaphragm |
Stainless steel 316L |
|
|
Long-term Stability |
≤0.2%F.S./year |
||
|
|
Isolation Ex-proof |
EXIA IIC T6 |
|
Product overview
WPT-EX2 is designed for hazardous area application. It is used for explosion-proof industry widely.
Features
Piezoresistive silicon chip employed
Hazardous area
application Isolation
explosion-proof Good
long term stability
Excellent linearity
