| Product name | KYIS130ACS24200-40L |
| Project name | Parameters |
| Rated voltage | 24V±10% |
| Limited supply voltage | 18-32V |
| Motor rated power | 3500W |
| Rated current | 110A±5% |
| Rated speed | 3000RPM |
| Rated torque | 9.55N·m |
| Maximum speed | 4000RPM (rated voltage) |
| Instantaneous maximum current | 200A±5% |
| Instantaneous maximum torque | 16 N·m |
| Number of poles | 10 |
| Feedback signal | Encoder |
| Applicable motor | 1500-3500W |
| Ambient temperature | -25-+50℃ |
| Insulation performance | Input and output to housing DC600V, leakage current 0.07mA; insulation resistance 20MΩ or more |
| Connector | TE 776286-1 (control end connector) |
| Three-proof requirements | Meet the three-proof requirements (dustproof, moisture-proof, salt spray-proof) |
| Relative humidity | 0% ~ 90%RH , with condensation (25°C) |
| Vibration requirements | Frequency 5HZ-25HZ, amplitude 3mm, 0.09g; 25HZ-200HZ, amplitude 1.47mm, 116g |
| Protection level | IP67 |
| Cooling method | Natural cooling |
| Weight | 9.8kg |
