Duplex Inline Filter SDFLND W 60 FDD 25A-1.X

4 month ago
0 0
Product details
--DIN 24550

--up to 400 L/min

--up to 25 bar

--material: aluminum

1.Technical Specification

1.1 Filter Housing

Construction

SDFLND Duplex inline filter consists of a filter head with built-in change-over valve and screw-in filter bowls. Standard filter is without bypass valve, but with plugs for vent and drain when delivery.

274 FLND

1.2 Filter Element

Filter elements are available with the following pressure stability values: BN/HC:20bar W/HC:20bar

2.General

Mounting: as inline filter

Temperature range: -30°C~+100°C

Pressure setting of clogging indicator: ΔPa=5bar-10%(others on request)

Pressure setting of bypass valve: ΔPo=7bar+0.5bar (others on request)



3.Application
Our products have been widely used in petrochemical, coal chemical, sewage treatment, nuclear power, agricultural machinery, steel plant, power plant, metallurgic plant, paper mill, medicine and other industries.

4.Certificates
ASME UNBCECE
