HH-TC3040LP Hydraulic hot stamping machine for book cover

6 day ago

3 0

KC Printing Machine (Group) Limited

 9 year year

Product details

Hydraulic embossing stamping machine // Hydraulic gold stamping machine

Usage and characters

Hydraulic hot stamping machines and oil-pressure hot stamping machines use the hydraulic system to generate pressure to achieve the hot stamping function. The hydraulic oil is pumped out from the oil tank through the hydraulic pump, and then transported to the hydraulic cylinder after pressurization to push the piston to move, so that the hot stamping plate connected to the piston generates pressure. Under a certain temperature and pressure, the electrochemical aluminum foil is hot stamped onto the surface of the substrate. • High and stable pressure: It can provide a large hot stamping pressure, generally ranging from a few tons to dozens of tons, and the pressure output is uniform and stable, which can ensure that the hot stamping pattern is clear and firm. • High precision: With high-precision temperature control and mechanical positioning system, the positioning accuracy can reach millimeter level or even higher, which can achieve hot stamping of fine patterns. • Strong adaptability: It can adapt to the hot stamping of various materials such as paper, plastic, leather, metal, etc., and can also meet the hot stamping needs of substrates of different thicknesses and shapes. It is used in the packaging and printing industry, such as hot stamping of cigarette boxes, wine boxes, cosmetic boxes, etc.; in label printing, it is used for hot stamping of various product labels; it can also be used for hot stamping of printed materials such as greeting cards, calendars, and book covers to enhance the beauty and added value of the products. 158

Hydraulic embossing and gilding stamping Machine //Parameter

HH-TC303030B

Hot plate area:300 ×400 mm
Working table area:480 ×600mm
Max printing pressure:20,000 Kg
Up and down distance:100mm
Heat wattage: 6×500W
Foil in feed: Motor Drive
Temperature adjustment:0-300oC .

HH-TC4040B

Hot plate area:400 × 400 mm
Working table area:480 ×600mm
Max printing pressure:20,000 Kg
Up and down distance:100mm
Heat wattage: 6×500W
Foil in feed: Motor Drive
Temperature adjustment:0-300oC

Hydraulic embossing and gilding stamping machine //Advantage

Bench made ofhigh strength cast steel forging, has a very high flatness and stability;
Thread rising institutions to adjust the table lift to facilitate the opening and closing of space according to the height adjustment of the product tipping machine;
Relay control program is running, easy operation, easy maintenance;
Pairs of buttons control the stamping head up and down, security is greatly enhanced;
Hydraulic drive instead of the pneumatic drive, stamping pressure significantly improve the stability is greatly enhanced;
Heating pipe heating, rapid heating, replacement is simple and convenient;
Heating plate can be removed to facilitate installation and replacement gilt template;
Ironing board and table parallelism can be adjusted to facilitate the flexible adjustment depending on the size of the different regions of the pressure;
Automatic temperature control system can be set depending on the product temperature, automatic temperature control; temperature control accuracy of about 5 degrees;
Hot foil stamping degree of time and rolls of time can be set freely according to different technical requirements;
Foil paper automatic document feeder, conveyor length can be set according to the size of the stamping area of freedom.
