What benefit YUKA air filter bring for you?
①Compressed air filter filtration efficiency up to 99.99%, manufacture according ISO8573.1-2010 standard Class 1
②Filter housing with 15 years warranty, filter element with 4000-6000 hours
③Low pressure drop, thanks for unique screw proceed technology and fluorine sealing ring
④Socket and flange connection for options, applied for all kinds of air compressor and Industries
⑤316 stainless steel housing material, cope with harsh environments
⑥Working pressure can be customized
How to select compressed air filter, here is some tips for you.
①Assess the requirements of your application. Different industry require different solution.
②What type of filtration is needed? Coalecent filter material removes solid and liquied contaminants from gas streams. Particulate filter media removes solid from gas streams. Absorber media removes hydrocarbon vapors from gas streams.
③Any specific micron of filtration performance you required?
④What are the working conditions of your application? Mainly criteria of consider : Flow, working pressure, temperature,pressure loss,material of structure (stainless steel, aluminum alloy, mild steel, carbon steel)
⑤Filter flow rate from how much SCFM? Pressure drop should be less than **bar? For saving the cost and protect environment.
Technical Specification
The flow rate below is the treatment capacity of compressed air under rated working pressure 7 barg (100psi g). For the application in other working pressure, please refer to the correction factors.
Model
Connection
Flow rate
Dimension(mm)
L/S
m³/min
scfm
Width(W)
Height(H)
A
B
G-BHL017
Rc1/2"
16.7
1.0
35.3
85
195
19.6
175.4
G-BHL025
Rc3/4"
25.0
1.5
53.0
85
195
19.6
175.4
G-BHL030
Rc1/2"
30.0
1.8
63.6
88
205
18.8
186.2
G-BHL035
Rc3/4"
33.3
2.0
70.6
88
205
18.8
186.2
G-BHL058
Rc3/4"
46.7
2.8
98.9
110
250
24.2
225.8
G-BHL068
Rc1"
60.0
3.6
127.1
110
250
24.2
225.8
G-BHL080
Rc1"
80.0
4.8
169.5
118
380
32.2
347.8
G-BHL145
Rc1-1/2"
120.0
7.2
254.2
118
380
32.2
347.8
G-BHL220
Rc2"
200.0
12.0
423.7
143
470
43.0
427.0
G-BHL260
Rc2-1/2"
233.3
14.0
494.4
143
470
43.0
427.0
G-BHL330
Rc2"
267.2
16.0
564.8
150
814
55.5
758.5
G-BHL360
Rc2-1/2"
317.3
19.0
670.7
150
814
55.5
758.5
G-BHL405
Rc2-1/2"
367.4
22.0
776.6
185
584
58.5
525.5
G-BHL430
Rc3"
467.6
28.0
988.4
185
584
58.5
525.5
G-BHL620
Rc3"
620.0
37.2
1313.6
185
814
58.5
755.5
Technical Requirement
Maxi.pressure：250barg, Maxi.working temperature: 90℃, Mini working :1.5℃
Pressure
Barg
14
16
18
20
Psig
203
232
261
290
20 bar Pressure Correction Factor
0.90
0.95
1.00
1.05
Pressure
Barg
4
6
8
10
15
20
30
40
50
Psig
58
87
116
145
218
290
435
581
726
50 bar Pressure Correction Factor
0.14
0.22
0.28
0.34
0.47
0.56
0.70
0.85
1.00
Pressure
Barg
20
30
40
50
60
70
80
90
100
Psig
290
435
581
726
871
1016
1161
1306
1451
100 bar Pressure Correction Factor
0.45
0.57
0.68
0.80
0.84
0.88
0.92
0.96
1.00
Pressure
Barg
-
-
50
100
150
200
250
300
350
Psig
-
-
726
1451
2177
2903
3628
4354
5080
350 bar Pressure Correction Factor
-
-
0.73
0.78
0.82
0.87
0.91
0.96
1.00
Element Performance
|
|
|
|
|
|
|
| PF | AO | AA | AX | ACS | AR | AAR |
| As a primary filter, particles whose diameter more than 5μm can be removed, the maximum residual oil contect is negligible. | High efficiency general protection, dust particles, water mist and oil mist whose diameter more than 1μm can be removed, the residual content of oil mist does not exceed 0.6mg/m³(21ºC), 1ppm(w). | High efficiency oil removal filtration, dust particles, water mist and oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.01mg/m³(21ºC), 0.01ppm(w). | Ultra-efficient filtration, dust particles, water mist and oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.001mg/m³(21ºC), 0.001ppm(w). | Dust particles whose diameter more than 0.01μm, oil vapor and odor can be removed, the maximum residual residual content of oil vapor does not exceed 0.003mg/m³(21ºC), 0.003ppm(w). | Dust particles whose diameter more than 1μm can be removed. | Dust particles whose diameter more than 0.01μm can be removed. |
International test and measurement standard ISO12500
>ISO 12500 has made clear a general test and definition method for the compressed air filter manufacturers. The main performance parameters
are the air inlet oil content and particles size distribution of the solid particles.
>ISO12500-1 specifies the test requirements for the filtration performance of oil aerosol in the coalescing filter.
>ISO12500-2 specifies the test requirements of adsorption filters for the removal performance of steam adsorption.
>ISO12500-3 specifies the requirements for removal of particulate matter from solid pullutants.
Products are tested with the international advanced testing equipment based on standard ISO12500,
which is equivalent to the standard ISO8573.
Filtration Grade
PF
AO
AA
AX
ACS
AR
AAR
Size of solid particles(ISO12500-3)
5μm
1μm
0.0μm
0.01μm
-
1μm
0.01μm
Filtration performance of solid particles(ISO12500-3)
-
99.999+%
99.999+%
99.999+%
99.999+%
99.999+%
99.999+%
Filtration performance of oil(ISO12500-3)
50%
80+%
99.9+%
99.99%
-
-
-
Residual oil content(ISO12500-1)
5mg/m³
0.6mg/m³
<0.01mg/m³
<0.001mg/m
<0.004mg/m³
-
-
Why choose YUKA as your long term business partner?
YUKA's YD series filters are ideal solutions for removing pollutants in compressed air systems and saving energy. Use imported quality filter materials and design technology to ensure high-quality compressed air quality and lower operating costs.
We have a full set of testing equipment imported from Europe. Filters and gas-water separators can be tested and rated according to ISO 8573.1: 2009
air quality standards, and provide performance test reports.
Packing & Shipping
Packing: Good packing will protect the goods from damage during transport. We use strong, durable packing material to pack the goods.
Shipping: By air,by sea ,by express
