Plastic Fast Recover High Voltage Diode
3KV 2CL03S Plastic Fast Recover High Voltage Diode 2CL0305
Maximum Ratings & Thermal Characteristics Ratings at 25℃ ambient temperature unless otherwise specified.
| Symbols | 2CL03S | Unit | ||
| ltem | ||||
| Repetitive Peak Reverse Voltage | VRRM | 3 | KV | |
| Average Forward Current | IF(AV) | 500 | (50HZ，Ta =25℃) | mA |
| (50HZ half-sine wave,Resistance load Ta=25℃) | ||||
| Non-Repetitive Forward Surge Current | IFSM | 0.5 (50HZ， 1/2，Ta = 25℃) (50HZ half-sine wave,1/2 cycle, Ta=25℃) | A | |
| Ambient temperature | Tamb | -40-+100 | ℃ | |
| Virtual Junction Temperature | TJ | 120 | ℃ | |
| Storage temperature | Tstg | -40-+120 | ℃ | |
Electrical Characteristics Ratings at 25℃ ambient temperature unless otherwise specified.
| Symbols | 2CL03S | Unit | |||
| ltem | |||||
| Forward voltage Drop | IF = 500mA | VF | 7 | V | |
| Normal Temperature Reverse Current | VR=VRRM | IRm1 | 2 | μA | |
| TA=100℃ High Temperature Reverse Current | VR=VRRM | IRm2 | 5 | μA | |
| IF=2mA , Irp=4mA 1mA recovery | trr | 100 | nS | ||
| Reverse Recovery Time | |||||
If you are interested in the product, contact 2bvideo.com for more information for more information
