RTM050M
RTM050M is a robust solar panel with 36 solar cells. These solar panels can be used for on-grid solar applications.Our meticulous design and production techniques ensure a high-yield, long-term performance for every solar panel produced. Our rigorous quality control and in-house testing facilities guarantee Restar's solar panels meet the highest quality standards possible. Choose our solar panels , we'll not let you down.
Product Details
![_(`IT}PF6]LL6JZSA)4QVDP](http://i.glbin.com/product/9e/b3/e2/3ee04657eb2077ed5e469e8be9.png "_(`IT}PF6]LL6JZSA)4QVDP")
Specification
ELECTRICAL DATA(STC)
STC: Irradiance 1000% W/m² , Cell Temperature 25°C,Air Mass AM 1.5 according to EN 60904-3
|
Rated Power in Watts-Pmax(wp)
|
50W
|
|
Open Circuit Voltage-Voc(V)
|
21.6V
|
|
Short Circuit Current-Isc(A)
|
3.06A
|
|
Maximum Power Voltage-Vmp(V)
|
18.20V
|
|
Maximum power current-Imp(A)
|
2.75A
|
|
Module Efficiency(%)
|
13.82%
|
ELECTRICAL DATA(NOCT)
NOCT:Irradiance at 800 W/m²,Ambient Temperature 20°C,Wind Speed 1 m/s.
|
Rated Power in Watts-Pmax(wp)
|
37.34W
|
|
Open Circuit Voltage-Voc(V)
|
21.02V
|
|
Short Circuit Current-Isc(A)
|
2.48A
|
|
Maximum Power Voltage-Vmp(V)
|
16.95V
|
|
Maximum power current-Imp(A)
|
2.20A
|
MECHANICAL DATA
Solar Cells
Mono-crystalline 156x52mm (36pcs)
Cell configuration
36cells(4x9)
Module dimensions
670*540*25mm
Weight
4.0KGS
Front Cover
3.2mm Tempered Glass
Frame Material
Anodized Aluminum Alloy
J-Box
IP65 or IP67, 1 Diodes
Cable
2.5mm2(IEC)/12AWG(UL),900mm
Connectors
MC4 or MC4 Comparable
Standard Packaging
5pcs/suite box
TEMPERATURE & MAXIMUM RATINGS
Nominal Operating Cell Temperature (NOCT)
45°C±2°C
Temperature Coefficient of Voc
-0.32%/°C
Temperature Coefficient of lsc
0.05%/°C
Temperature Cofficient of Pmax
-0.39%/°C
Operational Temperature
-40~+85°C
Maximum System Voltage
1000V(IEC)600V(UL)
Max Series Fuse Rating
10A
Limiting Reverse Current
10A
Company Profile
Resun Solar specializes in providing high quality and highly cost-effective solar panels. With its 2 manufacturing factories accredited by ISO9001 & 14001, full ranges of Resun panels are certified by TUV IEC61215,IEC61730,VDE, CEC,EMC,LVD,CE and approved PID free by PI-Berlin lab and insured by American CHUBB Insurance Group.
Founded in 2007 and with 600MW production capacity , Resun Solar has lots of experiences on medium and big size Ground projects based on MW and small individual rooftop system based on KW, and Resun Solar has more than 10 years experiences as qualified solar home system supplier for World Bank solar project, the projects distributes in most of Europe Countries, Australia, Canada, South America, Africa, Middle East and Asia.
Insisting on its goal to convenient customer and build win-win cooperation with the good relationship with different solar system components partners, Resun Solar has built an industry alliance to supply solar power system integration solutions and solar application products.
Sales and Service Network
Headquartered in China, Resun 's sales network covers more than 20 Countries, providing customers with instant after sales service and an efficient supply-chain, our clients can be found throughout the world, such as North America, Europe, Oceania, Eastern Europe, East Asia, Middle Easter and Africa etc.
