Shanding Brand
MAIN PARAMETERS:
| MODEL NO | GTJZD-10 | GTJZD-10L | GTJZD-12 | GTJZD-12L |
| MAX WORKING HEIGHT | 12.00m | 12.00m | 13.80m | 13.80m |
| MAX HEIGHT OF WORKING TABLE | 10.00m | 10.00m | 11.80m | 11.80m |
| RATED LOADING | 230kg | 320kg | 230kg | 320kg |
| RATED LOADING OF EXPANDING TABLE | 113kg | 113kg | 113kg | 113kg |
| WORKING TABLE SIZE | 2.26×1.13×1.1m | 2.26×1.13×1.1m | 2.26×1.13×1.1m | 2.26×1.13×1.1m |
| OVERALL SIZE (UNFOLD) | 2.475×1.17×2.469m | 2.475×1.17×2.469m | 2.475×1.17×2.597m | 2.475×1.17×2.597m |
| OVERALL SIZE | 2.475×1.17×2.019m | 2.475×1.17×2.019m | 2.475×1.17×2.149m | 2.475×1.17×2.149m |
| SIZE OF EXPANDING TABLE | 0.9m | 0.9m | 0.9m | 0.9m |
| MIN GROUND CLEARANCE | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m | 0.1/0.02m |
| WHEELBASE | 1.92m | 1.92m | 1.92m | 1.92m |
| MIN TURNING RADIUS | 3.1m | 3.1m | 3.1m | 3.1m |
| RATED POWER OF DRIVING MOTOR | 2×24V/1.1kw | 2×24V/1.1kw | 2×24V/1.1kw | 2×24V/1.1kw |
| RATED POWER OF RISING MOTOR | 24V/3.0kw | 24V/3.0kw | 24V/3.0kw | 24V/3.0kw |
| SPEED OF RISE &DECLINE | 3-5m/min | 3-5m/min | 3-5m/min | 3-5m/min |
| MAX WALKING SPEED(UNWORKING) | 4.0km/h | 4.0km/h | 4.0km/h | 4.0km/h |
| MAX WALKING SPEED OF WORKING | 0km/h | 0km/h | 0km/h | 0km/h |
| BATTERY TYPE | 4×6V/180ah | 4×6V/180ah | 4×6V/210ah | 4×6V/210ah |
| RECHARGER MODEL | 24V/25A | 24V/25A | 24V/25A | 24V/25A |
| MAX GRADE | 25% | 25% | 25% | 25% |
| MAX GRADE OF WORKING | 2°/3° | 2°/3° | 1.5°/3° | 1.5°/3° |
| TYRE SIZE(CARRIER WHEEL) | Φ250×80mm | Φ250×80mm | Φ250×80mm | Φ250×80mm |
| TYRE SIZE (SUPPORTING WHEEL) | Φ300×100mm | Φ300×100mm | Φ300×100mm | Φ300×100mm |
| WEIGHT | 2330kg | 2730kg | 2460kg | 2860kg |
|
|
|
|
|
|
If you are interested in the product, contact 2bvideo.com for more information for more information
