30A SCHOTTKY BARRIER RECTIFIER
YZPST-MBRD30100CT
Features:
Low power loss, high efficiency. High surge capacity
For use in low voltage, high frequencyinverters, free wheeling, and polarity protection applications.
Metal silicon junction, majority carrier conduction.
High current Capability, low forward voltage drop.
Guard ring for over voltage protection.
Absolute Maximum Ratings (Ta=25℃ unless otherwise noted)
|
Parameter |
Symbol |
Value |
Unit |
|
|
Maximum Recurrent Peak Reverse Voltage |
VRRM |
100 |
V |
|
|
Maximum RMS Voltage |
VRMS |
70 |
V |
|
|
Maximum DC Blocking Voltage |
VR(DC) |
100 |
V |
|
|
Maximum Average Forward Current |
IF(AV) |
30 |
A |
|
|
Peak Forward Surge Current:8.3ms single half sine-wave superimposed on rated load (JEDEC method) |
IFSM |
350 |
A |
|
|
Maximum Forward Voltage @IF=15A Tj=25℃ |
VF |
0.85 |
V |
|
|
Maximum DC Reverse Current |
Tj=25℃ |
IR |
0.1 |
mA |
|
Tj=125℃ |
20 |
mA |
||
|
Maximum Operating Junction Temperature |
Tj |
150 |
℃ |
|
|
Storage Temperature |
Tstg |
-40~+150 |
℃ |
|
Package Dimension
