CPD30 3 TON ELECTRIC FORKLIFT
JDY Electric Forklift is an ideal compact four-wheel electric lift truck solution for most indoor and warehouse applications. The Electric Forklift is capable of moving most any standard load while maintaining the ability to fully operate in small spaces . And JDY designed and built AC motors provide new levels of performance, efficiency, and reliability to maximize your productivity and return on investment.
MAIN PARAMETERS FOR CPD10 B
Model NO:
CPD30
Driving Mode
seated,
Rated Capacity
3000kg
Load Center Distance
500mm
Power Mode
lead-acid battery
Wheelbase
1175mm
Tyre Type
solid tyre
Wheels Qty(front/rear)
2/2pcs
Front track
910mm
Rear track
865mm
Tyre(front) Type
15X4 1/2-8
Tyre(rear) Type
15X4 1/2-8
front overhang
308mm
Tilt of the mast,front/rear
5/10°
Height OF mast retraction
2017mm
Maximum lift height
3000mm
Height OF mast extended
3957mm
Overhead guard height
1920mm
lateral Fork Adjustment(Outside of Forks)Max/Min
970/200mm
Forks Size(L*W*G)
30*100*920MM
Overall length(fork excluded)
1795
Overall width
1020
Min. turning radius
1800
Groud clearance Of mast
77
Ground clearance at center of wheelbase(loaden)
100mm
Width of aisle right-angle stacking(pallet1000x1000mm clearance 200mm)
3300mm
Width of aisle right-angle stacking(pallet1200x1200mm clearance 200mm)
3550mm
Max travel speed(loaden/unloaden)
7/8Km/H
Max Ascent speed(loaden/unloaden)
220/230MM/S
Max Decline Speed(loaden/unloaden)
550MM/S
Max. grade(loaden/unloaden)
15/20%
Weight(with battery)45
4530KG
Battery voltage / capacity8
0V/300Ah
Battery weight
207KG
Drive motor power-60 minutes
6KW
Lift motor power-15 minutes
6KW
Drive motor controlling mode
MOSFET/PMSM
Lifting motor controlling mode
MOSFET/PMSM
Service brake/parking brake
Hydraulic/Mechanial
Hydraulic system working pressure
14.5MPA
