The liquid water present in all compressed air systems causes pipeline corrosion, permanent damage to valves, cylinders, pneumatic tools and machinery, and reduces the efficiency of the aftercooler/heat exchanger.
By installing the YUKA WS series of high-efficiency gas-water separators, more than 99% of the liquid water can be removed easily and economically.
Your compressed air system will reduce downtime and maintenance costs, so it will operate more efficiently. The WS Air water separator will also improve the efficiency of downstream equipment such as aftercoolers, refrigeration dryers, filters, etc., enlarge the equipment life cycle and save costs.
Feature & Advantage
· Protect the coalescing filter from a large amount of liquid pollution
· Helps to provide air quality, in line with ISO8573-1:2010, the international standard for compressed air quality
· Suitable for all compressed air applications, suitable for all compressor types
· Low operating cost, low pressure loss, low life cycle cost
· All WS series gas-water separators are covered by a 15-year shell warranty
The water separator filter is compact and beautiful in appearance, durable, and the pressure loss is negligible. And there is an imported automatic drain valve inside, no need to replace components. It is not only an ideal component for screw compressors, but also an indispensable water removal device for general air compressor post-processing.
Removal of water in compressed air is the primary task of compressed air purification. The water entrained in compressed air will corrode pipelines, valves, instruments and equipment, resulting in increased production costs.
Scope of Application
1. Separation and recovery of compressed air condensate
2. Condensate separation in steam line
3. Air Separation of inlet/outlet of gas-liquid mixing part
4. Separate and discharge condensate in the vacuum system
5. Condensate separation after water cooling tower
6. Geothermal steam separator
7. Various other gas-liquid separation applications
Technical Specification
The flow rate below is the treatment capacity of compressed air under rated working pressure 7 barg (100psi g). For the application in other working pressure, please refer to the correction factors.
1.51
Model
Pipe Size
Flow rates
Dimension(mm)
L/S
m³/min
cfm
W(Weight)
H(High)
A
B
C (clearance for housing)
TWS009
RC1/4"
15.0
0.9
31.8
81
197
24.6
173.9
50.5
TWS010
RC3/8"
25.1
1.5
53.0
81
197
24.6
173.9
50.5
TWS011
RC1/2"
46.8
2.8
98.8
108
249
30.1
220.6
53.3
TWS012
RC3/4"
66.8
4.0
141.2
108
249
30.1
220.6
53.3
TWS014
RC3/4"
86.8
5.2
183.6
108
289
30.1
260.6
53.3
TWS016
RC1"
130.3
7.8
275.3
133
332
40.7
291
59.6
TWS018
RC1-1/2"
175.4
10.5
370.7
133
332
40.7
359.8
59.6
TWS020
RC2"
300.0
18.0
636.0
170
617
52.92
662.97
59.6
Technical requirements
Maximum operating pressure: 10barg Operating temperature: from 1.5℃ to 80°C
Pressure
Barg
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Psig
15
29
44
59
73
87
100
116
131
145
160
174
189
203
219
232
Correction factor
0.38
0.53
0.65
0.76
0.85
0.93
1.00
1.07
1.13
1.19
1.23
1.31
1.36
1.41
1.46
