Feature of DK77 seriers wire EMD cutting machine
Our company produce DK77 series CNC EDM wire cutting machine, models are complete, Strueture is reasonable.Rigidity is good and precision is high. High-grade machine adopts precision linear guide rail; High column optional/ equips electrk lifting roller span adjustment; Swinging big taper series machine tools equips wire electrode wire agencies； and produces semi-hermetic enviromental protection machinetools. Molybdenum wire diametr range from 0.12-0.2mm. Maximum processing speed is more than 100 mm2/min and the best surface roughness is equal to or smaller than Ra2.5um.
The CNC control is easy to operate and have powerful function.
Main Technical Parameters:
| Modal | Worktable size | WVorkalble travel | Max.cuting thickness | Processingtaper | Max.load weight | Mainmachine weigcht | Machine overallsize |
| DK7720 | 250x320mm | 200x250mm | 200mm | 6°/80mm | 100kg | 800kg | 1160x880x1400mm |
| DK7725 | 270x 420mm | 250x320mm | 400mm | 6°/80mm | 200kg | 1200kg | 1485x1010x1700mm |
| DK7732 | 380x600mm | 320x400mm | 400mm | 6°/80mm | 300kg | 1400kg | 1640x1280x1700mm |
| DK7740 | 410x710mm | 400x500mm | 400mm | 6°/80mm | 450kg | 1600kg | 1830x1490x1700mm |
| DK7745 | 500x750mm | 450x550mm | 400mm | 6°/80mm | 450kg | 1650kg | 1865x1520x1700mm |
| DK7755 | 596x880mm | 550x650mm | 500mm | 6°/80mm | 800kg | 2500kg | 2070x1770x1790mm |
| DK7763 | 790x1260mm | 630x1000mm | 600mm | 6°/80mm | 1000kg | 3500kg | 2265x1865x1980mm |
| DK7780 | 900x1500mm | 800x1200mm | 600mm | 6°/80mm | 1500kg | 5500kg | 2900x2500x2150mm |
| DK77100 | 1010x1500mm | 1000x1200mm | 600mm | 6°/80mm | 1500kg | 500kg | 2930x2500x2000mm |
| DK77120 | 1300x1900mm | 1200x1600mm | 600mm | 6°/80mm | 4000kg | 10000kg | 4200x3700x2000mm |
If you are interested in the product, contact 2bvideo.com for more information for more information
