Feature of DK71 seriers EMD Die Sinking Forming cutting machine
This series of machine tools are used with matched impulse electric cabinet Z axis is driven by Japan Sanyo DC servo motor; with a z axis numerical control feature. X,Y axis adopts precise ball screw and precision optical grating digital display shows the coordinate which make coordinates have high positioning accuracy. Electric cabinet adopts the most advanced industry-specific industrial control board, strong function, good stability simple operation, as long as input a few parameters such as Z axis depth, it will select a set of suitable date from the expert database system that matches the processing, and process from the rough processing to finish once automatically.
Main Technical Parameters
Modle
Unit
D7125
D7132
D7140
D7145
D7150
D7160
Worktable size
mm
400x250
500x200
650x400
720x450
800x500
1000x600
Worktank dimension
mm
1030x520x320
1050x560x320
1050x630x410
1400x710x410
1450x780x500
1680x850x580
X axis travel
mm
250
320
400
450
500
600
Y axis travel
mm
150
250
300
350
400
450
Z axis travel
mm
240
240+240
250+250
250+250
250*300
250+350
Distance between electrode tip surface and worktable
mm
400
550
650
680
700
800
Maxworkpiece weight
kg
250
550
750
800
800
1000
Max.electrode weight
kg
50
60
70
80
100
150
Mahine weight
kg
1100
1200
1800
2000
2200
3000
Machine dimension
cm
110x120x204
110x140x212
110x120x204
150x150x225
160x150x230
170x160x240
