MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS (single-phase,half-wave,60HZ,resistive or inductive load rating at 25°C,unless otherwise stated) |
||||
|
|
Symbol |
SR3KV |
units |
|
|
Maximum Recurrent Peak Reverse Voltage |
VRRM |
3000 |
V |
|
|
Maximum RMSVoltage |
VRMs |
2100 |
V |
|
|
Maximum DC blocking Voltage |
VDC |
3000 |
V |
|
|
Minimum ReverseBreakdown Voltage IR=100μA |
V(BR)R |
3100 |
V |
|
|
Average ForwardRectified Current half-sinewave |
IFAV |
0.25 |
A |
|
|
Peak Forward Surge Current 10ms half sine-wave |
lFSM |
15 |
A |
|
|
Maximum Forward Voltage at 0.25A |
VF |
5.0 |
V |
|
|
Non-repetitive peak reverse avalanche energy at leRR)=0.2A |
ER |
5.0 |
|
|
|
Maximum DC Reverse Current at rated DC blocking voltage |
Tj=25℃ Tj=125℃ |
lR |
10.0 100.0 |
μA |
|
Maximum Reverse Recovery Time (Note1) |
Trr |
250 |
nS |
|
|
Typical Thermal Resistance (Note 2) |
Rth(ja) Rth(jc) |
45 25 |
℃/W |
|
|
Typical Junction Capacitance (Note 3) |
Cj |
10.5 |
pF |
|
|
Storage and Operating Junction Temperature |
Tstg,Tj |
-55to+175 |
℃ |
|
|
Note: 1.Reverse Recovery Condition If=0.5A,Ir=1.0A,Irr =0.25A 2.Lead length I=10mm,TL=constant 3.Measured at 1.0 MHz and applied Vr=4.0V |
||||
|
Min |
3000.00 |
|
|
|
|
|
Min |
|
|
|
|
|
|
Max |
|
10 |
5 |
250 |
|
|
Max |
|
|
|
|
|
|
Condition |
IR |
VRRM |
IF |
|
|
|
Condition |
|
|
|
|
|
|
Bin1@ |
100 μA |
3000 V |
0.25 A |
If = 0.5A, Ir =1.0A, I rr =0.25A |
|
|
Bin1@ |
|
|
|
|
|
|
Item |
VRRM(V) |
IR( μA) |
VF(V) |
TRR(ns) |
|
|
Item |
|
|
|
|
|
|
1 |
3889 |
0.198 |
2.281 |
115 |
|
|
|
|
|
|
|
|
|
2 |
3867 |
0.097 |
2.179 |
126 |
|
|
|
|
|
|
|
|
|
3 |
3866 |
0.316 |
2.172 |
120 |
|
|
|
|
|
|
|
|
|
4 |
3974 |
0.18 |
2.18 |
124 |
|
|
|
|
|
|
|
|
|
5 |
3883 |
0.202 |
2.21 |
123 |
|
|
|
|
|
|
|
|
|
6 |
3813 |
0.189 |
2.201 |
122 |
|
|
|
|
|
|
|
|
|
7 |
3747 |
0.164 |
2.252 |
112 |
|
|
|
|
|
|
|
|
|
8 |
3958 |
0.184 |
2.418 |
112 |
|
|
|
|
|
|
|
|
|
9 |
3851 |
0.111 |
2.137 |
125 |
|
|
|
|
|
|
|
|
|
10 |
3818 |
0.115 |
2.202 |
116 |
|
|
|
|
|
|
|
|
|
11 |
3991 |
0.125 |
2.231 |
122 |
|
|
|
|
|
|
|
|
|
12 |
3735 |
0.184 |
2.629 |
96 |
|
|
|
|
|
|
|
|
|
13 |
3913 |
1.104 |
2.239 |
118 |
|
|
|
|
|
|
|
|
|
14 |
3932 |
0.128 |
2.461 |
106 |
|
|
|
|
|
|
|
|
|
15 |
3899 |
0.11 |
2.203 |
122 |
|
|
|
|
|
|
|
|
|
Min |
3735 |
0.097 |
2.137 |
96 |
|
|
|
|
|
|
|
|
|
Max |
3991 |
1.104 |
2.629 |
126 |
|
|
|
|
|
|
|
|
|
Avg |
3875.733 |
0.227133 |
2.26633 |
117.2667 |
|
|
|
|
|
|
|
|
