MODEL R.MO-3W,150K-J/TP
1.Dimension
|
Dimension（ｍｍ） |
L |
ФD |
ｌ |
Φd |
|
Value |
15.5±0.5 |
5±0.5 |
≥26 |
0.8±0.05 |
2 .Rated Value：
|
(Style) |
MO |
|
(Rated Power) |
3W |
|
(Derating Curve)
|
|
|
Rated Voltage |
 |
|
Maximum Voltage |
500V |
|
Maximum Overload Voltage |
700V |
|
Tolerance |
±5% |
|
Resistance Range |
150K |
|
Operating Temperature Range |
-55℃ ～ +155℃ |
3 Performance：
|
Description |
Performance Requirements |
Test Method |
|
|
(Resistance Temperature Coefficient) |
T.C.R. ±350ppm/℃ |
Test temperature +20℃／-55℃／+20℃／+125℃／+20℃ |
|
|
(Short-time Overload) |
△ Ｒ≤±1％Ｒ No visible damage,Markings legible |
2.5 times rated voltage or maximum overload voltage (the lower) 5 seconds |
|
|
(Wiith Standing Voltage) |
(No flasheover or breakdown) |
AC 500V 1 minute |
|
|
Terminal Strength |
Pulled |
△Ｒ≤±1％Ｒ+0.05R No visible damage |
Φd 0.8mm；Load 10N 10s |
|
Winded |
Φd 0.8mm；Load 10N 900 |
||
|
Twisted |
3600 in opposite direction |
||
|
Resistance to Vibration |
△Ｒ≤±1％+0.05R No visible damage |
10～500Hz 3 direction 2 hours each |
|
|
Solder-heat Resistance |
△Ｒ≤±1％Ｒ Marks legible ,no visible damage |
350℃ 2mm from the body,3 seconds |
|
|
(Solderability) |
At least 95% of the dipping surface must be covered by new solder, no flaws gathered. |
235℃ 2mm from the body, 2 seconds |
|
|
Temperature Cycle |
△Ｒ≤±1％Ｒ+0.05R No visible damage |
-55／+155℃ for 5 cycles |
|
|
(Humidity) |
△Ｒ≤±5％Ｒ+0.05R No visible damage |
40℃ 95％RH 1344 hours |
|
|
70℃ (Load Life) |
△Ｒ≤±5％Ｒ+0.05R No visible damage, marks legible |
rated voltage or maximum voltage,1.5 hours on, 0.5 hours off, 70 centigrade temperature 1000 hours |
|
4 Taping & Forming
Axial Lead Taping
