YHY Interchangeable plug power adapters are also belong to plug in type / wall mount type power adapter.But the different is the plugs of interchangeable plug power adapter the plug are removeable and changeable. We have US EU AU UK ect plugs for this AC/DC Adapter.
9v 1a, 9W wall mount interchangeable power supply with many different removable plugs,inculding US plug, CN plug, EU plug, Australia plugs and UK plugs in the kit.These plugs are detachable,which is very convenient if you often travel around the world.
US EU AU UK plug interchangeable AC/DC Power Adapter
|
Specification
|
|
|
|
Input Voltage Range
|
100-240Vac 50/60Hz
|
|
|
Output
|
9V 1A,9W
|
|
|
Temperature Coefficient
|
±0.05%/℃
|
|
|
Voltage Accuracy
|
±2%
|
|
|
Total Regulation
|
±5%
|
|
|
Ripple & Noise
|
120mV
|
|
|
Short Circuit Protection
|
Continuous - hiccup mode
|
|
|
Over Voltage Protection
|
110-150% of nominal (Cycle input power to reset)
|
|
|
Efficiency at Average Load
|
88% min
|
|
|
Operation Temperature
|
0 to ＋60℃, derating linearly to 50% load above 40℃
|
|
|
Storage Temperature
|
-10 to ＋85℃
|
|
|
Humidity (non condensing)
|
10-90% RH
|
|
|
Cooling
|
Convection
|
|
|
Withstand Voltage
|
Input to Output 3kVAC
|
|
|
Vibration (non condensing)
|
23.52m/s2 (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)
|
|
|
Shock
|
< 196.1 m/s2 (20G)
|
|
|
Safety Agency Certifications
|
UL62368,UL1310,UL60950-1, EN609501-1, IEC60950-1, CE Mark
|
|
|
DOE Regulation
|
VI
|
|
|
Off-Load Power Consumption
|
<210mV
|
|
|
Conducted & Radiated EMI
|
EN55023-B, FCC Class B
|
|
|
Immunity
|
EN55024
|
|
If you are interested in the product, contact 2bvideo.com for more information for more information
