YHY-15008000 AC/DC 15v 8a Desktop Power Adapter have EMI absorption ring, it also has to absorb EMI, the ability to absorb static pulse magnetic, electronic equipment to achieve compatible (EMI / EMC) and electrostatic discharge of corresponding international standards.Protection: short circuit protection, overcurrent protection, overcharge protection, over-discharge protection, high voltage protection, over power protection, thermal protection, electromagnetic protection.All copper nickel-plated plug, standard safety input jack, using a conductive material more pure steel, wear no deformation, and plug the test up to 3000 times, still can better ensure charging contacts.Also,it has ABS plastic shell, high temperature wear.
1. High efficiency and low operation temperature
2. AC input power suitable for the world
3. Soft-start current can reduce the AC input impact efficiency
4. With short-circuit and overload protection
5. Compact size ,light weight
6. 100%full-load burning test
7. Installed with EMI filter ,minimum wave
8.Global certifications: UL FCC CE GS KC PSE SAA RCM NOM RoHS
Specifications |
||
|
Input Voltage Range |
VAC |
100-240Vac 50/60Hz |
|
Input Current(Max) |
A |
2.5A(100VAC Input) |
|
Power Factor |
- |
Meets EN61000-3-2 |
|
Temperature Coefficient |
℃ |
±0.05%/℃ |
|
Voltage Accuracy |
% |
±2% |
|
Adjustment Range |
- |
None |
|
Min. Load |
A |
None |
|
Total Regulation |
- |
±5% |
|
Ripple & Noise |
mV |
120mV |
|
Short Circuit Protection |
% |
Continuous - hiccup mode |
|
Over Voltage Protection |
℃ |
110-150% of nominal (Cycle input power to reset) |
|
Efficiency at Average Load |
- |
88% min |
|
Operation Temperature |
- |
0 to +60℃, derating linearly to 50% load above 40℃ |
|
Storage Temperature |
- |
-10 to +85℃ |
|
Humidity (non condensing) |
- |
10-90% RH |
|
Cooling |
- |
Convection |
|
Withstand Voltage |
- |
Input to Ground 1.5kVAC, Input to Output 3kVAC (Output is connected to Ground) |
|
Vibration (non condensing) |
- |
23.52m/s2 (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour) |
|
Shock |
- |
< 196.1 m/s2 (20G) |
|
Safety Agency Certifications |
- |
UL62368,UL1310,UL60950-1, EN609501-1, IEC60950-1, CE Mark |
|
DOE Regulation |
- |
VI |
|
Off-Load Power Consumption |
mW |
<210mV |
|
Conducted & Radiated EMI |
- |
EN55023-B, FCC Class B |
|
Immunity |
- |
EN55024 |
