Drawbar Trailer 2 3 Axles

2 year ago

39 0

Shandong Tenda Vehicle Co. LTD

 2 year year

Product details

TENDA 3 Axles Fence Drawbar Dolly Full Trailer is a self-supporting, unpowered trailer which has at least one axle at either end of the trailer. The front axle is connected to a drawbar and the axle pivots to provide steering, following the direction in which the drawbar is pulled. This is sometimes called a dolly.The key differences between a semitrailer and a drawbar trailer are that a semitrailer does not have wheels at the front, it has a kingpin which fits inside a fifth-wheel or turntable coupling, and the front of the trailer is supported on the rear wheels of the prime mover.

TENDA BPW Axles Dollly Drawbar Drop Side Wall Board Fence Flatbed Deck Truck Traileris much flexible when running on the road and easy to turn the direction, which can also increase loading capacity of lorry and reduce fuel consumption.

Drawbar Trailer with Side Wall Fence
Model	QLV9400TDP
Dimension(Optional)	Axle No.	Rated Load (kg)	Tire No.	Tire Size
20ft	2	40000	8	12R20 12.00R 12R22.5 (Other Size / Single Super Tire Contact with Supplier)
40ft 45ft 48ft 53ft	3	60000	12
40ft 45ft 48ft 53ft	4	75000	16
Manufacture	Qingdao Luckin Vehicle Co., Ltd
Size	969026003060mm
Wheel Base (mm)	1310
leaf-spring Pcs	10
Axle	BPW 13/16/18 T
Suspension	Heavy Duty Mechanic Suspension with Leaf Springs
Main Beam Material	Q345B manganese plates, automatic submerged arc welded
Brake System	Dual line braking system with automatic braking system/chambers
Brake Air Chamber	Double Model
Kingpin	2' or 3.5' Interchangeable
Landing gear	28T loading capacity with 80T static lifting capacity.
Platform	4-6 mm diamond steel plate
Brake System	Dual Lines Braking System With Automatic Air Chambers
Brake Air Chamber	Two double and One single chamber
Electrical System	24V, 7core socket, lights according to European standards.
Mainbeam Size	Upper plate	14mm
	Lower plate	16mm
	Mid Web	6 mm
	Height	500mm
Pin Height	According to the height of the tractor saddle.
Application	For 2x20ft or 1x40ft containers/bulk cargo transport
Sidewall Height	300mm 600mm 800mm 1200mm 2000mm by needs
