Lowbed semi trailer also be named Lowboy trailer, Low loader trailer, Drop deck trailer, Low deck trailer, Low loader. Generally the normal low bed semitrailer loading capacity is from 30T-120T. For the special loading on loading capacity or cargo szie, customized is necessary.
Low loader trailer is the most classic type of low deck and heavy haulage, and all the other lowbed trailers like RGN trailer, Folding neck trailer , Extendable lowbed trailer are designed based on the original feature of conventional lowbed trailer.
Gooseneck,long cargo platform, the rear end with whell and ramp, the three parts are the main structure of low loader.
Ultra-low deck,long cargo platform, heavy haulaging are the common features of lowbed trailer.
2 Axles Heavy Duty Lowbed Trailer
2
35-50T
3 Axles Heavy Duty Lowbed Trailer
3
50-65T
4 Axles Heavy Duty Lowbed Trailer
4
65-85T
2 Line 4 Axles Lowbed Trailer
4
80T+
3 Line 6 Axles Lowbed Trailer
6
100T+
4 Line 8 Axles Lowbed Trailer
8
120T+
5 Line 10 Axles Lowbed Trailer
10
150T+
Multi Axle Heavy Duty Lowbed Trailer
5+
85T-120T
Hydraulic Folding Gooseneck Lowbed Trailer
2,3,4,5,6,
35T-80T
Gooseneck Detachable Lowbed Trailer
2,3,4,5,6
35-85T
Extendable Lowbed Trailer
2,3,4,5,6
35-80T
Capacity:20,00kg to 120000kg can be customized made, which depends on customers and use specify.
Type:
2 axles front load lowbed semi trailer
3 axles front load lowbed semi trailer
4 axles front load lowbed semi trailer
Lowbed Chassis:
Folding Gooseneck Low Loader has been produced in welding constructions with gas metal arc welding as "I" crossing from high resistant steel considering overloads proper to capacity and intended usage.
Front Load Low-bed Semi-Trailer Dimensions:
Platform length:
Various depends on intended usage(customized)
Width: 2500 mm - 4500 mm varies according to demand.
Platform (Pool ) Height: Varies depending on intended usage. Pool Height: 500 mm (Min) - 1400 mm (max)
Main beam
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B,T700,Q355B welded by automatic Submerged-Arc processes.
Frame Beam
Top Flange 14mm,width 140mm; Middle Flange 8mm; Bottom Flange 16mm,width 140mm, main beam height 500mm
Loading Capacity
30-150T
Dimension
Length and width dimensions available custom made
Axle number
2,3,4 axles to 7, 8 Axles
Axle Brand
BPW,FUWA,Yuek,
Suspension
Mechanical, Hydraulic, Air suspension
Pneumatic Braking System
Dual line pneumatic brake system,T30 air chamber ,40L air tanks, WABCO Emergency relay valve
Ramp
Mechanical spring or hydraulic lifting ramp
Landing Gear
two speeds, manual operating
Accessories
One standard tool box
Spare tire rack
One
Electrical system
24 volt electrical system.7 pin electrical connector. Parking stop, reverse, number plate and indicator lights. rear lights conform to European standard, rear front and side reflectors
Painting
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
