Design advantage: The Refrigerated Air Dryers has many attributes that are key to remarkable, innovative dryer design with hign quality operating characteristics to provide a liquid-free compressed air system
High ambient operating temperatures: The YUKA refrigerated air dryer is designed for high temperature and high relative humidity ambient, It can operate under max.45℃,65 ℃maxi.inlet air temperature, and match brand air compressor. The air dryer use state of art, high efficiency extended surface heat exchangers. This design minimizes pressure drops whilst maximizing thermal productivity, thus optimizing the dryer performance under adverse operating conditions.
3-1 Heat exchanger: The heat exchanger(s) are an integrated, aluminum channel design. They are designed to pre-cool the inlet air, reduce the air stream to the needed dewpoint and reheat the air prior to discharge.
R410 A Refrigerant: Environmentally friendly R410A, a non-ozone depleting refrigerant, is used in YUKA air dryer, R410A is not on any list for global obsolescence.
Filter (Option): An industrial grade air filter comes on YUKA air dryers to help protect the dryer from ingress of dust.
Moisture separator (Option) with integral automatic drains：YUKA Air Dryer Desiccant use a multi-action moisture separator to ensure water is separated from the compressed air stream, after the evaporator. Optimum efficiency is gained with the use of large flow, solenoid operated drain valves. This ensure that you get dry air for your process requirements.
Hot Gas By-pass Valve: The key to constant dew point control is the hot gas bypass valve. YUKA air dryers used the finest valve of the world. The use of this valve in the refrigeration system ensure that your YUKA air dryer will provide you with a contant low dew point, resulting in dry air.
Low Noise: YUKA air dryers are also fitted with a sound proof enclosure, to ensure working without noise.
Perfect Protection Functions: YUKA air dryers has the perfect self-protection for its refrigerant compressor. Including compressor overload, fan motor overload, refrigerant hign pressure/low pressure protection, electric current overload, phase loss etc.
| Model | Flow Rate (m³/min) | Power Supply | Input Power (kw) | Air line Connection | Refrigerant Type | G.W.(kg) | Measurement (mm) |
| HL010 | 1.2 | 220V 50Hz | 0.37 | RC3/4" | R134a | 34 | 480*380*665 |
| HL020 | 2.4 | 220V 50Hz | 0.52 | RC3/4" | R134a | 42 | 520*410*725 |
| HL030 | 3.6 | 220V 50Hz | 0.73 | RC 1" | R410a | 50 | 580*460*785 |
| HL060 | 6.5 | 220V 50Hz | 1.26 | RC 1 1/2" | R410a | 63 | 700*540*910 |
| HL080 | 8.5 | 220V 50Hz | 1.87 | RC 2" | R410a | 73 | 770*590*990 |
| HL100 | 11.0 | 220V 50Hz | 2.43 | RC 2" | R410a | 85 | 770*590*990 |
| HL120 | 13.5 | 220V 50Hz | 2.63 | RC 2" | R410a | 94 | 800*610*1030 |
| HL150 | 17.0 | 380v 50Hz | 3.00 | DN50 Flange | R407c | 180 | 1000*850*1143 |
| HL200 | 23.0 | 380v 50Hz | 3.70 | DN65 Flange | R407c | 210 | 1100*900*1203 |
| HL250 | 27.0 | 380v 50Hz | 5.80 | DN80 Flange | R407c | 350 | 1200*950*1273 |
| HL300 | 33.0 | 380v 50Hz | 6.10 | DN80 Flange | R407c | 420 | 1450*1000*1350 |
| HL400 | 42.0 | 380v 50Hz | 8.00 | DN100 Flange | R407c | 550 | 1550*1100*1403 |
| HL500 | 55.0 | 380v 50Hz | 9.20 | DN100 Flange | R407c | 680 | 1680*1300*1600 |
| HL600 | 65.0 | 380v 50Hz | 10.10 | DN100 Flange | R407c | 780 | 1750*1450*1680 |
| HL800 | 85.0 | 380v 50Hz | 12.00 | DN125 Flange | R407c | 920 | 1950*1500*1900 |
