| Specification of HZ-L series CNC vertical lathe | ||||
| Description | HZ600L | HZ750L | HZ900L | |
| Maximum swing diameter | Ø600mm | Ø750mm | Ø900mm | |
| Maximum cutting length | 600mm | 650mm | 700mm | |
| Maximum cutting diameter | Ø500mm | Ø600mm | Ø850mm | |
| Spindle form and code name | A2-8 / 6 (spindle unit) | A2-8 / 11 (spindle unit) | A2-11 (spindle unit) | |
| Spindle speed | 10-2500 rpm | 10-2000 rpm | 80-1500 rpm | |
| number of spindle speeds | stepless | stepless | stepless | |
| Spindle transmission ratio | 1:2（3） | 1:2（3） | 1:2（3） | |
| Main motor output power | 11/15KW | 18.5/22KW | 22KW | |
| Spindle output torque | 140NM | 236/280 NM | 280NM | |
| Chuck diameter / form | 300/400（K3L ） | 500（K3L ） | 630（K3L ） | |
| X-axis servo motor | 1.6Kw-10Nm | 2.4Kw-15Nm | 2.7Kw-18Nm | |
| Z-axis servo motor | 1.8Kw-15Nm | 2.4Kw-15Nm | 2.7Kw-18Nm | |
| Turret main motor kw (optional) | 3.7/5.5 | 3.7/5.5 | 3.7/5.5 | |
| Turret | Horizontal Turret | 8 or 12 tools | 8 or 12 tools | 8 or 12 tools |
| Power Turret | 12 tools | 12 tools | 12 tools | |
| Row Turret | Row knife seat | Row tool seat | Row tool seat | |
| Guide rail structure | Roller line rail | Z axis 45 | Z axis 45 | Z axis 55 |
| X axis 35 | X axis 45 | X axis 45 | ||
| Z-axis ball screw | R 4010 | R 4010 | R 5008 | |
| X-axis ball screw | R 3210 | R 4010 | R 5008 | |
| X-axis rapid speed m / min | Line rail | 15 | 18 | 18 |
| Z-axis rapid speed m / min | Line rail | 15 | 18 | 18 |
| X axis travel | -50~+230mm | -50~+350mm | -50~+450mm | |
| Z axis travel | 600mm | 700mm | 700mm | |
| Electrical capacity | 16KVA | 16KVA | 30KVA | |
| The machine tool weight | 5.5 Ton | 7 Ton | 8.5Ton | |
| Dimension---L/W/H | 1650/1750/2700 (unbalanced cylinder block) | 2100/2000/3100 (unbalanced cylinder block) | 2400/2100/3200 (unbalanced cylinder block) | |
If you are interested in the product, contact 2bvideo.com for more information for more information
