Material:
Hardox 450 or equal wear and abrasion-resistant material box, T700 high tension beam, tare weight lighter 2000kg than normal material tipper, longer service time and lower fuel consumption
U section box:
U model box design and analysis, larger section area with lower barycentre, load more and unloading easier, safely and efficiently
Chassis:
Double web for main beam design, stronger for multi road condition
Cylinder:
FC and FE model optional, higher operating pressure, help Max 45° tilt angle, reducing turnaround time with faster-ripping speed, increasing operating time with long service intervals
Brackets:
Improved design with better stress and fatigue resistance
Knock off:
Robust design precise actuation protect box working in safety angle
Tilt Shaft:
Heavy-duty design support working stable when tilting, more durable and safety
Fasten Sys:
Rear door auto fasten lock efficiency work, adjustable design keep suitable situation, easy maintenance and replace
Auxiliary support frame:
An auxiliary support frame support box with chassis, avoid box tilt, in order to work more safely
|
Dimension |
12500×2,500×3,230mm |
|
Body Inside |
12100×2,500×1,500mm |
|
Volume |
30-70 ton |
|
Floor |
6-8mm High strength steel |
|
Sidewall |
3-5mm High strength steel |
|
Beam |
Domex 600 or equal steel “I” section double web |
|
Cylinder |
6 set bottom cylinder |
|
Axle |
3/4/6 Axles, tandem axle |
|
Tire |
12.00R20 / 13R22.5 or customized |
|
Suspension |
Mechanical / Air / Bogie optional |
|
Leg |
JOST exchangeable type |
|
Brake |
Dual air brake system, WABCO chamber and valve |
|
Elec sys |
12v/24v, 7 line cable, Led light |
|
Dimension |
12500×2,500×3,230mm |
|
Body Inside |
1210000×2,500×1,500mm |
|
Volume |
30-70 ton |
|
Floor |
6-8mm High strength steel |
|
Sidewall |
3-5mm High strength steel |
|
Beam |
Domex 600 or equal steel “I” section double web |
