product information
8 Axle Superlink flatbed semi trailer
Tare weight:20000kg
Payload 120000kg
Overall length:21000mm
Overall width:2500mm
Overall height:1500mm
Chassis:Heavy duty and extra durability designed i beam;opting for high tensile steel Q345,welded by automatic submerged-Arcprocesses.Top flange 14mm,width 140mm;middle flange 8mm;bottom flange 16mm;width 140mm
Axle number:8,Brand:Optional upon choice,capacity:13T
suspension:mechanical suspension or air suspension,
Leaf spring:Leaf spring or air bag
Floor:checkered plate
Tire:11.00R20,12.00R20,11R22.5,12R22.5,315/80R22.5 Tire optional
Wheel rim:8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice
Kingpin:2"/3.5"bolt-in king pin
Landing gear:JOST brand two-speed,manual operating,heavy duty landing gear
Twist lock:12no.of ISO twist lock for 1*20ft,2*20ft, 1*40ft container
Vehicular applications:container (20ft,40ft..)transporrt
Braking system:WABCO RE6 relay valer;T30/30 Spring brake chamber;40L air tanks
Painting:Complete chassis sand blasting to clean rust,1coat of anticorrosive prime,2coats of final paint
Accessories:One standard tool box.
Spare tire carrier:2spare tire carrier without spare tires
If you are interested in the product, contact 2bvideo.com for more information for more information
